How to optimize the construction process through real-time monitoring data of laser leveling machine?

  1. High-precision leveling: – With the help of a concrete laser leveling machine, the operation is carried out based on the precise plane reference formed by the laser beam. The laser receiver feedbacks the deviation information in real time, and the leveling machine automatically and accurately adjusts the scraper height and vibration frequency to ensure that the floor flatness error can be controlled within a very small range, usually within ±2mm, providing a solid foundation for subsequent processes, especially suitable for precision manufacturing workshops, high-end storage facilities and other places with strict requirements on flatness. 2. Excellent wear resistance: – In the initial setting stage of concrete, diamond wear-resistant materials are evenly spread. With its high hardness and high strength, it is closely integrated with the surface of concrete. After smoothing and finishing, a solid and wear-resistant protective layer is formed, which greatly improves the wear resistance of the floor, effectively copes with high-intensity wear scenes such as heavy-loaded vehicles and frequent cargo handling, and significantly extends the service life of the floor. 3. Unique corrugated compartment joint design: – Abandoning the traditional straight compartment joint, the corrugated compartment joint is adopted. This design not only meets the needs of concrete expansion and contraction and prevents cracks, but also has a better stress dispersion effect than the straight joint, which can effectively reduce the risk of cracks caused by uneven foundation settlement and temperature changes. It can also add a unique visual beauty to the floor and enhance the overall image of the site. 4. High efficiency of construction: – All construction links are closely connected, from base treatment, concrete pouring, laser leveling, to wear-resistant material spreading, compartment joint setting and subsequent maintenance, all in one go and in an orderly manner. Laser leveling technology greatly improves the leveling efficiency. Compared with traditional manual leveling methods, the construction speed can be increased several times, which greatly shortens the overall construction period and reduces the project construction cost.   It is widely used in various large-scale and high-load indoor and outdoor concrete floor projects, such as large industrial plants, logistics distribution centers, airport aprons, exhibition halls, port terminal cargo yards and other places, especially for projects with high requirements for floor flatness, wear resistance and crack resistance, and the expectation of a certain aesthetics.   1. Laser leveling principle: – The laser transmitter releases a rotating laser beam to form a high-precision horizontal control surface. The laser receiver installed on the leveling machine continuously captures the laser signal, compares the real-time elevation of the floor with the laser reference surface, and transmits the generated deviation signal to the control system, prompting the hydraulic mechanism of the leveling machine to respond quickly, accurately control the scraper, vibrator and other components, and realize fast and accurate leveling and vibration of the concrete, achieving a high-precision leveling effect. 2. The wear-resistant principle of corundum: – When the concrete is in the initial setting state and the surface has a certain viscosity, the spread corundum particles can be embedded in the surface of the concrete. With the subsequent leveling and finishing operations, the corundum is deeply combined with the concrete. With its excellent hardness and wear resistance, it builds a solid defense line against wear on the concrete surface, protecting the main structure of the floor from friction loss in daily use. 3. The anti-cracking principle of the corrugated compartment joint: – Compared with the straight joint, the curved shape of the corrugated compartment joint can more effectively disperse the stress during the expansion and contraction of the concrete. When the concrete needs to expand and contract due to factors such as temperature rise and fall and foundation settlement, the corrugated joint guides the stress to disperse along the curve to avoid excessive stress concentration, thereby reducing the possibility of cracks and ensuring the integrity and stability of the floor.     1. Construction preparation: – Technical preparation: Read the construction drawings in detail, clarify the technical requirements, prepare a rigorous construction plan, and organize construction personnel to conduct technical briefings. – Site preparation: Thoroughly clean up debris and accumulated water on the construction site, ensure that the base is flat, and take reinforcement measures for weak bases; reasonably plan the temporary drainage system for construction; design the concrete pouring and leveling route and the layout of the compartment joints according to the shape and area of ​​the site. – Material preparation: Strictly purchase high-quality cement, sand, admixtures, diamond wear-resistant materials, etc. according to design requirements, strictly inspect the raw materials to ensure that the quality meets the standards; prepare sufficient water and electricity for construction. – Equipment preparation: Comprehensively debug concrete laser leveling machines, concrete mixing equipment, transportation equipment, wear-resistant material spreaders, trowels, etc. to ensure that the equipment is in good operating condition; accurately calibrate the laser system to ensure that the emitted laser plane matches the floor design elevation. 2. Base treatment: – Deeply clean the base to remove dust, oil and other pollutants; compact the base with a roller or compacting machine, with a compaction degree of not less than 90%; use concrete or mortar to repair and level the local potholes and holes on the base, so that the base leveling error is controlled within ±10mm. 3. Concrete pouring: – Accurately weigh the raw materials according to the designed mix ratio, use a forced mixer to fully mix the concrete, and the mixing time is not less than 90 seconds to ensure the uniformity of the concrete; use pumping or self-unloading to transport the concrete to the construction area, control the pouring speed, prevent concrete segregation, and the pouring thickness should be slightly higher than the designed floor elevation by 10-20mm to reserve operating space for subsequent leveling. 4. Laser leveling: – Turn on the laser leveling machine and keep moving at a constant speed, usually controlled at 1-2m/min; the operator flexibly adjusts the scraper height and vibration frequency of the leveling machine in real time according to the signal fed back by the laser receiver to ensure that the concrete surface is flat and vibrated densely; the leveling work of adjacent areas must be completed before the initial setting of the concrete, and the overlapping construction width must be no less than 10cm to ensure the integrity of the floor. 5. Spreading of wear-resistant materials: – When the concrete is initially set (generally there are slight footprints when stepping on it, and the sinking depth is about 3-5mm), use a special spreader to evenly spread the diamond wear-resistant material on the floor surface according to the specified amount, and the spreading thickness is approximately 3-5mm; during the spreading process, the spreading speed and direction must be accurately controlled to prevent the accumulation or leakage of wear-resistant materials, and ensure that the spreading uniformity reaches more than 90%. 6. Smoothing and finishing: – After the wear-resistant material is spread, use the trowel to smooth it immediately. The trowel should be operated in a crisscross pattern to make the wear-resistant material fully blend with the concrete. The number of smoothing times should be no less than 3 times. As the concrete continues to harden, when there is no water stain on the surface and it feels slightly hard when pressed with fingers, it should be smoothed manually. Aluminum alloy rulers, trowels and other tools should be used to make the floor surface bright and smooth. 7. Corrugated compartment joint setting: – Before the concrete is finally set, according to the pre-designed compartment joint layout, a special mold or cutting equipment is used to make a corrugated compartment joint. The mold or cutting tool should ensure that the depth of the joint reaches 1/3 – 1/4 of the thickness of the concrete slab, and the joint width is controlled at 5 – 10mm. During the production process, the shape of the joint should be regular and smooth, and the anti-cracking and aesthetic functions of the compartment joint should be effectively exerted. 8. Maintenance: – After finishing and setting the compartment joints, the floor shall be maintained in time by covering with plastic film, spraying curing agent or laying water straw mats, etc. The maintenance time shall not be less than 7 days. During this period, the concrete surface must be kept moist to avoid cracks caused by water loss; warning signs shall be set up during the maintenance period, and vehicles and pedestrians are strictly prohibited from passing on the floor that does not meet the strength requirements.   1. Flatness Quality Control: – Before construction, use professional instruments to finely calibrate the laser system to ensure the accuracy of the laser plane; during the construction process, regularly use a 2m ruler and feeler gauge to check the flatness, at least once every 100-200 square meters, and adjust the leveler immediately if deviation is found; after finishing, use a laser flatness meter to comprehensively test the flatness of the floor to ensure that it meets the design requirements. 2. Wear-resistant performance quality control: – Select diamond abrasive wear-resistant materials strictly according to design requirements, and carefully check quality certification documents; in the spreading process, strengthen on-site supervision to ensure that the spreading amount and uniformity meet the standards; after maintenance, on-site wear resistance tests can be carried out, such as grinding a certain area with a grinding wheel, observing the wear condition, and judging whether the wear resistance meets the standards. 3. Partition seam quality control: – When making partition seams, strictly control the depth, width and shape of the seams, and use precise measuring tools for inspection; regularly inspect the partition seams to check whether there are debris blocking them. If problems are found, clean and repair them in time to ensure that the partition seams function normally.   1. Organize construction personnel to participate in safety training to familiarize them with the operating specifications and safety precautions of various construction equipment (such as laser leveling machines, concrete mixers, cutting equipment, etc.). 2. Set up safety warning signs in conspicuous locations on the construction site to clearly divide the construction area and non-construction area to prevent unrelated personnel from entering the construction danger zone. 3. Regularly conduct safety inspections on construction equipment, focusing on electrical insulation, mechanical protection devices, etc., to ensure the safe operation of equipment and prevent safety accidents caused by equipment failure. 4. Provide construction personnel with complete personal protective equipment, including safety helmets, safety shoes, gloves, etc., to ensure the personal safety of construction personnel.   1. Classify and collect solid waste such as concrete residues and discarded diamond abrasive material packaging bags generated during the construction process, and regularly transport them to designated garbage disposal sites. 2. Reasonably plan construction time, avoid high-noise concrete mixing, equipment operation and other operations during residents' rest periods, and take noise reduction measures when necessary, such as installing silencers on equipment. 3. Strengthen the control of dust on construction sites, cover material storage sites, close transport vehicles, regularly sprinkle water to reduce dust, and maintain a clean environment on the construction site.   1. Economic Benefit: – High-precision laser leveling combined with efficient construction process greatly shortens the construction period and reduces labor, equipment rental and other cost expenditures; diamond abrasive wear-resistant floor reduces the cost of later maintenance and floor replacement; corrugated compartment seams reduce the cost caused by crack repair, and the comprehensive economic benefits are significant. 2. Social Benefit: – Provide high-quality floor solutions for large-scale industrial, logistics and other projects to meet the needs of industry development; reduce construction noise, dust and other pollution, and help environmental protection and urban sustainable development.   In a large automobile manufacturing plant construction project, this construction method was used, with a construction area of ​​more than 80,000 square meters. The floor flatness error is precisely controlled within ±1.5mm, meeting the requirements for the installation of precision equipment on the automobile production line; the diamond abrasive wear-resistant layer effectively resists the wear caused by the transportation of production equipment and vehicle driving; the corrugated compartment seams are beautiful and have no cracks, providing a solid guarantee for the efficient and stable operation of the plant, and have been highly praised by the owner. For example, in the renovation project of a busy port terminal cargo yard, this construction method also achieved remarkable results. A large area of ​​floor was quickly built with excellent wear and crack resistance, which met the high-intensity operation needs of the port and greatly improved the cargo yard operation efficiency.

  If the power trowel does not rotate flexibly or gets stuck, it is a serious mechanical failure. It must be stopped immediately for inspection; otherwise, it will further damage the engine or transmission mechanism. To accurately determine the cause, please follow the core principle of "separate first, then judge" and conduct the investigation through the following steps:     This step is key to determining the scope of the problem. Remove the spark plugs: First, remove the spark plugs to prevent the engine from starting unexpectedly during operation and ensure safety. Try turning the engine: Pull the starting rope quickly by hand. At this point, two situations will arise: Situation A: The engine shaft rotates flexibly. This indicates that the internal components of the engine (such as the piston, crankshaft, and connecting rod) are basically normal, and the fault point is most likely in the transmission mechanism or the working head. Situation B: The engine shaft is completely stuck and won't turn. This indicates that the malfunction occurred inside the engine and the problem is rather serious.     Now it is necessary to further determine whether the problem lies with the clutch, gearbox or blade assembly. Inspect the blade (smear) assembly Phenomena and Judgments Blade deformation/scratches: Observe with the naked eye whether all blades are flat and whether there is any bending or deformation caused by hitting the ground or foreign objects. When the deformed blades rotate, they will scrape against the machine's base plate or the ground, generating huge resistance. Bearing damage: This is a very common cause. Rotate the blade disk directly with force by hand and feel: Can it rotate smoothly? Is there any lag or "clicking" sound? Hold the blade disc with your hand and shake it up and down or left and right. Is there any obvious gap or loose feeling? If any of the above feelings occur, it indicates that the bearing supporting the blade disc has been worn or damaged and needs to be replaced. Check the transmission gearbox (for gear-driven power trowel) Phenomena and Judgments Open the oil filling hole or observation hole of the gearbox to check whether the gear oil is sufficient and whether it has deteriorated (such as turning black or containing metal shavings). If the gear oil dries up or is insufficient, the gears will wear out rapidly or even get stuck under dry friction. If you hear abnormal noises inside or find it very difficult to turn, it might be that the gears are damaged. Check the clutch (for centrifugal clutch type polishing machines) Phenomena and Judgments The clutch block may fail to open or retract normally due to spring failure, uneven wear or poor lubrication, resulting in friction and jamming with the clutch cup. If the engine rotates normally at low speeds but gets stuck or makes abnormal noises as soon as it accelerates, the possibility of clutch failure is relatively high. This is a more serious situation. Possible causes include: Lack of lubrication in the engine can lead to "cylinder seizure" or "bearing seizure". Judgment: Check whether the engine oil level is severely insufficient or there is no engine oil at all. The reason is that when the engine operates with no or little oil, the high-speed friction between the piston and the cylinder, as well as between the crankshaft and the bearing bush, generates high temperatures, causing the metal to melt and stick together, eventually getting stuck. It is usually accompanied by a pungent burnt smell. Damage to internal components Problems with the connecting rod and crankshaft: Bending of the connecting rod and damage to the crankshaft bearing can lead to internal motion interference and jamming. Valve problem: Extremely rare, but if the valve breaks and falls into the cylinder, it will press against the piston and prevent rotation. Engine overheating The heat sink was severely clogged with cement and oil stains, causing the engine to overheat. The piston, due to excessive thermal expansion, lost the gap with the cylinder wall, resulting in "thermal seizing". Sometimes, after the engine cools down, it may resume rotation. The following order will be the most efficient for troubleshooting: Engine oil level: This is the primary and essential item to check. Blade condition: Observe with the naked eye for any obvious deformation or scratch marks. Remove the spark plugs, pull the start rope, and determine whether the problem lies with the engine or the working head. If the engine is normal: Focus on checking the blade disk bearings (shaking and rotation tests) and the gearbox oil. If the engine is stuck and the engine oil is insufficient, it is very likely that the engine is "seizing the cylinder" or "seizing the bearing", and a major overhaul is needed. If the engine oil is normal, it could also be due to internal mechanical damage. Safety Tip: Do not forcibly start or use the machine until the problem is thoroughly investigated and resolved, as this may cause catastrophic secondary damage. For internal engine malfunctions and bearing replacements and other repairs, if you have no experience, it is recommended that you send them to a professional repair shop for handling.   Note: The parameters provided in this document are for reference only and are not mandatory. Due to differences in technical characteristics between different brands and models of laser levelers, please consult the manufacturer for a suitable solution before actual operation. This reference document assumes no responsibility for any issues arising from failure to follow the manufacturer's instructions.

When the concrete laser leveling machine fails, it needs to be repaired. Generally speaking, maintenance is a good way to help the leveling machine to restore health, but some leveling machines still have a lot of small problems after maintenance. What is this ? In fact, because some maintenance personnel in the maintenance of concrete laser leveling machine, the error caused by the error, the following error in the maintenance of concrete laser leveling machine when do not make it again.
