– Different building structure types and usage functions have clear steel mesh spacing requirements in the design specifications. For example, for general concrete slab structures, according to the "Concrete Structure Design Code", the spacing of steel bars should not be less than 70mm, when the slab thickness is not more than 150mm, the steel bar spacing should not be more than 200mm; when the slab thickness is more than 150mm, the steel bar spacing should not be more than 1.5 times the slab thickness, and should not be more than 250mm. For structures with special requirements, such as basement top slabs, hydraulic structures, etc., the specifications may have stricter regulations. – Through structural mechanics calculations, determine the load size, distribution, and force transmission path of the concrete structure during use. According to the calculation results, the steel mesh is reasonably arranged to meet the bearing capacity and deformation requirements of the structure. For example, in a two-way slab subjected to a large bending moment, in order to effectively resist the bending moment in both directions, it is necessary to determine the spacing of the steel mesh in different areas according to the bending moment diagram. Generally speaking, in areas with large bending moments, the spacing of the steel mesh should be appropriately reduced to provide sufficient bending resistance; while in areas with small bending moments, the spacing of the steel mesh can be appropriately increased, but it must meet the minimum spacing requirements of the specification. – Consider the pouring method of concrete and the performance of the vibration equipment to ensure that the concrete can fully wrap the steel bars and vibrate densely during the pouring and vibration process. If the spacing of the steel mesh is too small, it will affect the fluidity of the concrete and the insertion of the vibrator, making it difficult to pour the concrete densely, and it is easy to have quality problems such as honeycombs and rough surfaces; if the spacing is too large, it will affect the restraint of the steel bars on the concrete and reduce the integrity of the structure. For example, when pumping concrete, due to the large fluidity of the concrete, the spacing of the steel mesh can be relatively small, but it is also necessary to ensure that the vibrator can be smoothly inserted for vibration. In general, in order to facilitate the operation of the vibrator, the net spacing of the steel mesh should not be less than 1.5 times the diameter of the vibrator. – Steel bars of different specifications and types have different bearing capacities and deformation properties, which will affect the determination of the spacing of the steel mesh. For example, high-strength steel bars can withstand greater tensile forces, and their spacing can be appropriately larger than ordinary steel bars on the premise of meeting the structural force requirements. For steel bars with larger diameters, in order to ensure sufficient bonding between the steel bars and concrete, and to avoid excessive concentration of steel bars leading to difficulties in concrete pouring, the spacing of the steel meshes also needs to be increased accordingly. Generally speaking, the larger the diameter of the steel bar, the larger the spacing of the steel meshes should be. For example, when using steel bars with a diameter of 10mm, the spacing may be 150-200mm; and when using steel bars with a diameter of 12mm, the spacing may be 180-250mm. In actual projects, the determination of the spacing of the steel meshes needs to be determined by professional structural engineers based on the specific project conditions, taking into account the above factors, through rigorous calculation and analysis, and following relevant design specifications and standards to ensure the safety, applicability and durability of the structure.

    This is an excellent, specific question. Vanse offers a range of concrete laser leveling machines with telescopic booms (like the YZ40-4E), and their maintenance philosophy is critical for machine longevity and leveling accuracy.1 Based on the general requirements for all laser levelings and the guidelines provided by Vanse, here is an expert summary focusing specifically on the telescopic boom. Vanse emphasizes comprehensive maintenance, including regular checks on lubrication points and the overall integrity of the machine.2 The key to maintaining a Vanse telescopic boom is managing friction, eliminating "slop," and aggressively fighting concrete abrasion. While some specialized brands (like Ligchine) advise strictly against grease on the boom tubes, Vanse machines often follow a more traditional heavy-duty equipment approach for their structural moving parts, requiring you to locate and service specific grease points. Zerk Fittings: Vanse machines have designated lubrication points (zerk fittings) on structural pivots, the leveling head, and potentially internal boom components like rollers or cylinders. You must consult your specific Vanse operation or maintenance manual for the location and frequency of these points. Expert Tip: When greasing any part on the boom near the telescoping tubes, be extremely careful not to over-grease. Wipe away all excess grease immediately, as it will attract concrete dust, forming an abrasive paste that damages the boom wear pads.Cylinder piston rod: Check for any scratches, bends or continuous leakage. Chain Lubrication: If your model uses an internal chain drive for boom extension, ensure the chain is regularly lubricated with the specified chain oil or Open Gear Lubricant (OGL) and that the tension is checked often. The most critical maintenance for your FF/FL numbers is ensuring the telescopic boom sections are supported properly to prevent lateral or vertical movement ("slop"). The Check: Fully extend the boom and manually attempt to wiggle the end section up/down and side-to-side. There should be almost zero discernible play. Any movement compromises the accuracy of your leveling head. The Process: Wear pads (shims) and rollers guide the boom. As they wear, the clearance increases. Regularly inspect the pads for deep scoring or embedding of concrete grit. Grit requires immediate cleaning or pad replacement. Refer to your Vanse manual for the specific procedure to add shims or adjust the tensioners/rollers. Maintaining the correct clearance is essential. Vanse guidelines stress the importance of cleaning, and for the boom, this is the most effective preventative maintenance. Concrete Slurry: Use a power washer to clean off all concrete slu rry and dust immediately after the pour. Hardened concrete on the boom tubes and the leveling head acts as abrasive sandpaper on the wear pads every time the boom moves. Hydraulic Rods: Pay special attention to the hydraulic cylinder rods that move the boom and leveling head. Ensure they are clean before retraction. Dust or concrete on the rod will damage the seals inside the cylinder, leading to premature hydraulic failure. Pressure maintenance: For the lifting cylinder, observe whether there is obvious "sinking" (i.e., internal leakage) after it is lifted.   Maintenance Task Frequency Purpose Clean Boom Tubes After Every Use Prevent abrasive wear (scoring) and remove weight buildup. Grease Bearings/Pivots After Every Use / Daily Purge concrete slurry from high-speed bearings (e.g., auger, vibrator) and lubricate structural pins. Inspect Wear Pads/Rollers Weekly / Monthly Check for slop/wobble. Adjust clearance to maintain optimal tightness. Check Hydraulic Hoses Daily Inspect for rubbing, chafing, or kinks, especially where they track inside the boom.   Note: The parameters provided in this document are for reference only and are not mandatory. Due to differences in technical characteristics between different brands and models of laser levelers, please consult the manufacturer for a suitable solution before actual operation. This reference document assumes no responsibility for any issues arising from failure to follow the manufacturer's instructions.

  Concrete with large slump: The mixing time needs to be appropriately increased, generally 30-60 seconds longer than concrete with small slump, to ensure that the concrete is mixed evenly, so that the excess water is fully mixed with cement and other materials to avoid segregation. At the same time, the amount of water should be strictly controlled and accurately measured, because the amount of water has a greater impact on the slump. Concrete with small slump: When mixing, pay attention to controlling the mixing force and time to avoid excessive mixing that causes the concrete to be too dry and hard, and lose good workability. Generally, the mixing time is relatively short, so that all materials can be evenly mixed. Concrete with large slump: Prevent concrete from segregation and water evaporation during transportation. The mixer truck should maintain a uniform speed, avoid sudden braking and sharp turns, and reduce the shaking of the concrete in the tank. At the same time, the tank body can be covered with a sunshade to prevent direct sunlight from causing water to evaporate too quickly and affect the slump. Concrete with small slump: During transportation, care should be taken to prevent excessive loss of concrete slump. If the transportation time is long, some plastic preservation measures can be considered, such as adding an appropriate amount of retarder. However, attention should be paid to the amount of retarder added to avoid affecting the setting time and strength of the concrete. Concrete with large slump: The pouring speed should not be too fast and should be controlled within a certain range, such as the pouring volume per minute should not exceed 1-1.5 cubic meters to avoid rapid flow and accumulation of concrete in the formwork, resulting in loose vibration or segregation. At the same time, it is necessary to avoid excessive free fall height of concrete. When it exceeds 2m, auxiliary tools such as string barrels and chutes need to be used. Concrete with small slump: Due to its poor fluidity, some auxiliary measures are needed during pouring to ensure that the concrete can fill every corner of the formwork. For example, artificial auxiliary spreading can be used to evenly distribute the concrete in the formwork to avoid concrete accumulation or local vacancies. Concrete with large slump: It is advisable to use a low-frequency vibrator, and the vibration frequency is generally 2000-3000 times/minute. Avoid using a high-frequency vibrator to cause over-vibration of the concrete. The vibration time should not be too long. The vibration time at each point should be controlled within 20-30 seconds, and the concrete surface no longer sinks significantly, no bubbles appear, and cement slurry appears on the surface. Concrete with small slump: It is usually necessary to use a high-frequency vibrator, and the vibration frequency is generally 3000-5000 times/minute to improve the fluidity and density of the concrete. The vibration time should be appropriately extended, and the vibration time at each point may take 30-40 seconds to ensure that the concrete is vibrated and dense, but it is also necessary to prevent excessive slurry on the concrete surface due to over-vibration. Concrete with large slump: When finishing, wait for the surface moisture to evaporate properly before proceeding, generally 1-2 hours after the concrete pouring is completed. The specific time is determined according to the site environment and the concrete coagulation. Usually 2-3 times of plastering are required to eliminate moisture and defects on the surface. Plastic film, geotextile, etc. should be used to cover the surface immediately during curing to prevent the water from evaporating too quickly and causing the surface to lose water and crack. The curing time is generally not less than 14 days. Concrete with small slump: Plastering can be done in time after the concrete surface is slightly dry, generally about 0.5-1 hour after pouring. Due to its low moisture content and fast surface drying, fewer plastering times may be required, but attention should be paid to the plastering quality to ensure that the surface is flat and smooth. It should also be covered and moisturized in time during curing. The curing time is generally not less than 7 days, but if the environment is dry or the temperature is high, the curing time should be appropriately extended.
