What damage will improper blade angle adjustment cause to the power trowel blade?
April 17, 2025

Improper adjustment of the power trowel blade angle will cause the following damage to the blade
Accelerated wear
– When the blade angle is too large, the contact angle between the blade and the concrete surface is too vertical. During the troweling process, the friction and shear force on the blade will increase. This will cause the material on the blade surface to wear faster, making the blade edge blunt and reducing the service life of the blade.
– If the blade angle is too small, the contact area between the blade and the concrete surface will increase, and the pressure per unit area will decrease. However, since it takes longer and more troweling operations to achieve the desired effect, the number of frictions between the blade and the concrete will increase, which will also accelerate the wear of the blade.
Deformation
– When the angle is too large, the pressure and torque on the blade during work are large, which can easily cause the blade to bend and deform. This deformation may be more obvious when working continuously for a long time or handling hard concrete.
– If the angle is too small, although the pressure on a single blade is relatively small, due to the uneven overall force, the blade will be subjected to uneven force during rotation, which may also cause the blade to twist or deform in the long run.
Cracks or even breaks
– Due to improper angle adjustment, the blade will be subjected to abnormal stress during operation. When the stress exceeds the bearing limit of the blade material, cracks will appear on the blade surface. If the cracked blade continues to be used, the crack may gradually expand and eventually cause the blade to break.
– When the angle is too large, the impact force on the blade is greater, which is more likely to cause cracks and breaks; when the angle is too small, the blade will also crack due to fatigue under repeated unbalanced stress, increasing the risk of breakage.
